-C&I product with battery rack DC-switches
-Three-phase four-leg design, support 100% unbalanced load
-IP66 protection degree for harsh environment
-Supports multi-module parallel connection, enabling accurate management of battery
-PQ, VSG working mode

main parameters

Model	ESNV130K-AI-G01
DC Input
DC Voltage Range	650~950V
Max. DC Current	230A
AC Output
Rated Power	130kW
Max. Output Power	143kW
Reactive Power Range	0~136.5kvar
AC Connection	3W+N+PE
Isolation	Non-isolation
On-grid
Rated Grid Voltage	400V
Voltage Range	340~440V
Rated Grid Frequency	50Hz / 60Hz
Frequency Range	46.5Hz~51.5Hz / 56.5Hz~61.5Hz
THDi	<3% (at rated power)
Power Factor	-1~1
Charge-discharge Conversion Time	<100ms
Off-grid
Rated Output Voltage	400V
Voltage Imbalance	<2%, No more than 4% in a short period of time
THDu	<3% (no load or rated resistive load)
Voltage Transient Range	<30% Within 100ms, <10% After 100ms
Voltage Transient Range	(resistive load/balanced load. load change suddenly from 20% to 100% or from 100% to 20%)
Overvoltage Protection	Settable value
Undervoltage Protection	Settable value
General Data
Ground System	TT / TN
Operating Ambient Temperature Range	-40℃~+60℃ (derating above 45℃)
Allowable Relative Humidity Range	0~95%
Allowable Altitude Range	<4000m (derating above 3000m)
Noise Level	80dB
Anti-corrosion Degree	C4 (C5 is optional )
Surge Protection	Type ІІ Surge Protective Device (8 / 20μs)
Wiring Method	Quick plug terminal
Protection Degree	IP66
Indicator	LED indicator
Communication Interface	Ethernet / RS485 / CAN
Communication Protocol	Modbus TCP / Modbus RTU / CAN 2.0
Dimensions (WHD)	807643267mm (excludes hanging board)
Weight	Approx. 85kg (net weight)
